Induction Heating Units

Standard Option
UNIT: AF-30kw
TYPE: 30kw Split Type


High frequency versions available as a custom option.

Click the RFQ button to start talking to us about your heat induction needs!

Category:
  • Description

    Product Description

    The standard LinearGS AF-30kw Induction Heater is set up for non-ferrous screw coating, but can be configured for many other applications, including but not limited to:


    HEAT INDUCTION APPLICATIONS
    Annealing Hardening
    Bonding Heat Treatment for Gear and Shaft
    Carbide Tipping Joint Brazing
    Casting Powder Material Melting
    Catheter Tipping Preheating / Post Heating
    Forging More

    Don’t see an application process for your product?

    Bring us your Induction Heater requirements and we’ll find a solution that works for you!

  • Additional information

    Additional Information

    Model

    AF-30kw

    Maximum Output Power

    30KW

    Output Frequency

    50-150khz

    Output Current

    7-70 amps

    Input

    3x480v 50 or 60 hz

    Duty Cycling

    100%

    Connecting Cable Length

    6.5 feet / 2 m

    Cooling Water Temp

    Not to exceed 104°F / 40°C

    Water Type

    Soft Water Only

    Weight of Generator

    64lbs / 29kg

    Weight of Transformer

    53lbs / 24kg
